RCA-215 Ridewell Suspension

RCA-215

Non-Steerable Auxiliary Axle Suspension

Designed for the aftermarket installer.

Compact mounting envelope with 10.25″ of total travel.

22,500 lb. capacity

RCA-215 Suspension Travel Chart
RCA-215 Suspension Diagram

Overview
The RCA-215 is designed for OEM or aftermarket installers, with flexible features allowing for ease of installation with various configurations. Speed Set™ easy axle alignment system and axle integration is available. A host of optional features include a disc brake option, pre-plumbed air tank, and shock kit.

Features

• 10.25″ of total travel, up to 7″ of lift
• Durable and lightweight FiberTech™ bushing
• Secure axle alignment – .375″ at each hanger
• Accepts axle drop up to 8″
• Wide beam spacing reduces axle stresses
• Premium rubber cavity bushing
• Shear top pivot bolt
• 22.K capacity
• Ride heights 7.5″-18″
• 5″ diameter axle integration optional, straight or drop axles
• Field installation friendly
• Huck bolt fasteners
• Wide or narrow track available

Applications
• On-road or construction
• Available for truck or trailer applications
